Product Details:
|
| Dimensions: | 5 X 10mm² | Product Name: | Free-standing GaN Substrates |
|---|---|---|---|
| Thickness: | 350 ±25µm | TTV: | ≤ 10µm |
| Dislocation Density: | From 1 X 10⁵ To 3 X 10⁶cm⁻² | Macro Defect Density: | 0cm⁻² |
| Highlight: | GaN gallium nitride wafer,gan semiconductor substrate,gallium nitride wafer SI type |
||
5*10.5mm2 SP-face (20-21)/(20-2-1) Un-doped SI-type free-standing GaN single crystal substrate Resistivity > 106 Ω·cm RF devices wafer
Overview
Gallium Nitride (GaN) substrate is a high-quality single-crystal substrate. It is made with original HVPE method and wafer processing technology, which has been originally developed for many years. The features are high crystalline, good uniformity, and superior surface quality.
| (20-21)/(20-2-1) face Free-standing GaN Substrates | ||||
| Item |
GaN-FS-SP-U-S |
GaN-FS-SP-N-S |
GaN-FS-SP-SI-S |
Remarks: A circular arc angle (R < 2 mm) is used for distinguishing the front and back surface. |
| Dimensions | 5 x 10 mm2 | |||
| Thickness | 350 ±25 µm | |||
| Orientation |
(20-21)/(20-2- 1) plane off angle toward A-axis 0 ±0.5° (20-21)/(20-2- 1) plane off angle toward C-axis - 1 ±0.2° |
|||
| Conduction Type | N-type | N-type | Semi-Insulating | |
| Resistivity (300K) | < 0.1 Ω·cm | < 0.05 Ω·cm | > 106 Ω·cm | |
| TTV | ≤ 10 µm | |||
| BOW | - 10 µm ≤ BOW ≤ 10 µm | |||
| Front Surface Roughness |
< 0.2 nm (polished)； or < 0.3 nm (polished and surface treatment for epitaxy) |
|||
| Back Surface Roughness |
0.5 ~1.5 μm option: 1~3 nm (fine ground); < 0.2 nm (polished) |
|||
| Dislocation Density | From 1 x 105 to 3 x 106 cm-2 | |||
| Macro Defect Density | 0 cm-2 | |||
| Useable Area | > 90% (edge exclusion) | |||
| Package | Packaged in a class 100 clean room environment, in 6 PCS container, under a nitrogen atmosphere | |||
Appendix: The diagram of miscut angle
If δ1= 0 ±0.5°, then (20-21)/(20-2- 1) plane off angle toward A-Axis is 0 ±0.5°.
If δ2= - 1 ±0.2°, then (20-21)/(20-2- 1) plane off angle toward C-Axis is - 1 ±0.2°.
