High Purity Al2O3 50mm Sapphire Substrate Wafer Thk 430μm

Certification
China Shanghai GaNova Electronic Information Co., Ltd. certification
I'm Online Chat Now

High Purity Al2O3 50mm Sapphire Substrate Wafer Thk 430μm

High Purity Al2O3 50mm Sapphire Substrate Wafer Thk 430μm
High Purity Al2O3 50mm Sapphire Substrate Wafer Thk 430μm

Large Image :  High Purity Al2O3 50mm Sapphire Substrate Wafer Thk 430μm

Product Details:
Model Number: JDCD08-001-001
Payment & Shipping Terms:
Packaging Details: Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.
Payment Terms: T/T

High Purity Al2O3 50mm Sapphire Substrate Wafer Thk 430μm

Description
Surface Orientation: A-Plane(11-20) Material: High Purity Al₂O₃(>99.995%)
Thickness: 430±15μm R-plane: R9
Diameter: 50.8 ±0.10 Wafer Edge: R-type
Highlight:

50mm Sapphire Substrate

,

A Plane polishing sapphire crystal

,

Sapphire Substrate Thk 430um

JDCD08-001-001 Diameter 50mm Sapphire substrate wafer , Thk 430μm, crystal orientation C/M0.2, OF length (mm) 16 LED chip,substrate material

The substrate is prepared from sapphire, which is a material with a unique combination of chemical, optical, and physical properties. Sapphire is highly resistant against thermal shocks, high temperatures, sand erosion, and water.

In practical production, the sapphire wafer is made by cutting the crystal bar and then grinding and polishing. Generally, the semiconductor wafer is cut into a wafer by wire cutting or multi-wire cutting machine.

Parameters

Specification
Unit Target Tolerance
Material High purity Al2O3(>99.995%)
Diameter mm 50.8 ±0.10
Thickness μm 430 ±15
Surface Orientation C-Plane(0001)
-Off Angle toward M-axis degree 0.20 ±0.10
-Off Angle toward A-axis degree 0.00 ±0.10
Flat Orientation A-Plane(11-20)
-Flat Off-set Angle degree 0.0 ±0.2
Flat Lenght mm 16.0 ±1
R-plane R9
Front surface Roughness(Ra) nm <0.3
Back surface Roughness μm 0.8~1.2μm
Front surface Quality Mirror Polished,EPI-Ready
Wafer edge R-type
Chamfer amplitude μm 80-160
Included angle radian between flat edge and round edge mm R=9
TTV μm ≤5
LTV(5x5mm) μm ≤1.5
Bow μm 0~-5
Warp μm ≤10
Laser mark   As customer required
