Product Details:
|
| Package Type: | Surface Mount, Standard Package | Operating Temperature: | 15-55℃ |
|---|---|---|---|
| Wavelength: | 915nm | Output Power: | 10 |
| Slope Efficiency: | 1.0W/A | Emitter Size: | 94μm |
| Threshold Current: | 0.5A | Power Conversion Efficiency: | 58% |
| Highlight: | 915nm Laser Diode Chip,chip on submount laser diode,Laser Diode Chip 94um |
||
Laser Diode Chip Printing Surface Mount Standard Package 915nm
915nm 10W COS Diode Laser Chip On Submount Design
Main application is medical, laser lighting, free space optical communication.
The conversion efficiency of our chip can reach 60%, and lifetime can be more than 10000 hours.
In addition, the chip also adopts new epitaxial structure design and material epitaxy,
advanced non-pump window design and preparation technology,
and wet and dry etching combined with self-aligned process technology to control the consistency of the strip width,
especially to increase the manufacturing yield, also to reduce laser chip cost.
|
Optical
|
|
|
Center Wavelength
|
915nm
|
|
Output Power
|
10W
|
|
Spectral Width FWHM
|
≤6nm
|
|
Slope Efficiency
|
1.0W/A
|
|
Fast Axis Divergence
|
60Deg
|
|
Slow Axis Divergence
|
11Deg
|
|
Polarization Mode
|
TE
|
|
Emitter Size
|
94um
|
|
Electrical
|
|
|
Threshold Current
|
0.5A
|
|
Operating Current
|
12A
|
|
Operating Voltage
|
1.65V
|
|
Power Conversion Efficiency
|
58%
|
|
Thermal
|
|
|
Operating Temperature
|
15-55℃
|
|
Storage Temperature
|
-30-70℃
|
|
Wavelength Temp. Coefficient
|
0.3nm/℃
|
