Product Details:
|
| X-axis Cutting Speed: | 0.1 ～ 600mm/s | Product Name: | DAD3350 Automatic Dicing Saw |
|---|---|---|---|
| Max. Workpiece Size: | Φ8 Inch (250mm × 250mm, Φ300mm User-specified Specification) | Application: | 1.8kW, 2.2kW |
| Machine Dimensions(W×D×H)mm: | 900 × 1,050 × 1,800 | X-axis Cutting Range: | 260mm |
| Highlight: | 0.1mm/s Wafer Dicing Machine,wafer saw machine 260mm,600mm/s Wafer Dicing Machine |
||
DAD3350 Wafer Dicing Machine 0.1 ～ 600mm/s X-Axis Cutting Range 260mm
Improved throughput
The DAD3350 achieves improvement in throughput by increasing the speed of each axis.
Ease of use
Operability is improved with installation of an LCD touch screen and Graphical User Interface (GUI). Easy operation is achieved with a visual display showing processing conditions and various statuses with icon buttons. In addition, operation commonalities were considered in order to achieve easy replacement from the 300/500 series (existing models).
Process quality
By adopting a high-rigidity bridge-type frame and a spindle front-section support structure, which prevents heat shrinkage and vibration, a more stable processing point can be achieved.
Specifications
|
Specification |
Unit |
1.8 kW |
2.2 kW |
|
|---|---|---|---|---|
|
Max. workpiece size |
- |
Φ8 inch (250 mm × 250 mm, Φ300 mm user-specified specification) |
||
|
X-axis |
Cutting range |
mm |
260 |
|
|
Cutting speed |
mm/s |
0.1 ～ 600 |
||
|
Y-axis |
Cutting range |
mm |
260 |
|
|
Index step |
mm |
0.0001 |
||
|
Index positioning accuracy |
mm |
0.002/260 |
||
|
Z-axis |
Max. stroke |
mm |
32.2 |
31.4 |
|
Moving resolution |
mm |
0.00005 |
||
|
Repeatability accuracy |
mm |
0.001 |
||
|
θ-axis |
Max. rotating angle |
deg |
380 |
|
|
Spindle |
Rated torque |
N・m |
0.29 |
0.70 |
|
Revolution speed range |
min‐1 |
6,000 ～ 60,000 |
3,000 ～ 30,000 |
|
|
Machine dimensions(W×D×H) |
mm |
900 × 1,050 × 1,800 |
||
|
Machine weight |
kg |
Approx. 1,200 |
||
* Product appearance, features, specifications, and other details may change due to technical modifications.
* Please read the standard specification sheet thoroughly before use.
