Product Details:
|
| Thickness: | 430±10μm | Flat Edge Width: | 16±1.0mm |
|---|---|---|---|
| TTV: | ≤5μm | BOW: | ≤-8~0μm |
| Front Surface Roughness: | ≤0.25nm | Back Surface Roughness: | 0.8~1.2μm |
| Highlight: | PSS Sapphire Substrate,TTV 5um dsp wafer,Laser Making PSS Sapphire |
||
Back Laser Making Patterned Sapphire Substrates BOW ≤-8~0μm TTV≤5μm
2inch Patterned Sapphire Substrates,LED Chip,Substrate Material
And, the enhancement in the internal quantum efficiency benefits from the reduction of threading dislocations by possible lateral growth of GaN epilayer on the patterned sapphire substrate.
Patterned Sapphire Substrates (PSS) is a micro-patterned sapphire substrate. It has been widely used in high-power GaN-based Light Emitting Diodes (LEDs), which are the most promising alternative light source for general lighting.
| 2inch Patterned sapphire substrate | ||
| Item | Al2O3 |
|
| Dimension | 50.80±0.10mm | |
| Thickness | 430±10μm | |
| Flat edge width |
16±1.0mm |
|
| Flat edge angle | A-plane±0.2o | |
| TTV | ≤5μm | |
| BOW | ≤-8~0μm | |
| Front Surface Roughness | ≤0.25nm | |
| Back Surface Roughness | 0.8~1.2μm | |
| Edge | Round | |
| Laser making | back | |
