2 Inch Thick Film Aluminum Nitride Wafer AIN On Sapphire Wafer Al Face

Certification
China Shanghai GaNova Electronic Information Co., Ltd. certification
I'm Online Chat Now

2 Inch Thick Film Aluminum Nitride Wafer AIN On Sapphire Wafer Al Face

2 Inch Thick Film Aluminum Nitride Wafer AIN On Sapphire Wafer Al Face
2 Inch Thick Film Aluminum Nitride Wafer AIN On Sapphire Wafer Al Face

Large Image :  2 Inch Thick Film Aluminum Nitride Wafer AIN On Sapphire Wafer Al Face

Product Details:
Place of Origin: Suzhou China
Brand Name: GaNova
Certification: UKAS/ISO9001:2015
Model Number: JDWY01-001-001
Payment & Shipping Terms:
Packaging Details: Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.
Payment Terms: T/T

2 Inch Thick Film Aluminum Nitride Wafer AIN On Sapphire Wafer Al Face

Description
Product Name: Aluminum Nitride Wafer Dimensions: φ50.8mm±0.1mm,OF(1-100),Al Face,Locating Edge 16.0± 1.0mm
Substrate: Sapphire(Single Or Double Side Polished) Conduction Type: Semi-Insulating
Edge Exclusion Zone: <2mm Surface Roughness: Ra<1.5nm(10*10μm)
Highlight:

2 Inch Film Aluminum Nitride Wafer

,

AIN On Sapphire Wafer Al Face

,

Sapphire Aluminum Nitride Wafer

2 Inch Thick Film (1,2)μm AIN On Sapphire Wafer φ50.8 mm±0.1 mm,OF(1-100),Al Face,Locating Edge 16.0± 1.0mm

2 Inch Thick Film (1,2)μm AIN On Sapphire Wafer SSP XRD FWHM Of(002)≤80arcsec(102) ≤650arcsec UV Disinfection LED Chip



The material is stable at high temperatures under an inert atmosphere. It has a protective oxide layer that protects the material at up to 1370degC. It is also stable in hydrogen atmospheres up to 980degC. It can be dissolved or hydrolyzed by strong alkali, but is resistant to most molten salts and cryolite. This is why it is so useful in microelectronics.



Item AlN-T-C-U-C50
Dimensions φ50.8 mm±0.1 mm, OF(1-100), Al Face, Locating Edge 16.0± 1.0 mm
Substrate Sapphire( Single or Double Side Polished)
Thickness 1~5μm
Orientation

C-plane (0001)±1o

Conduction Type Semi-Insulating
Crystalline Quality Thickness XRD FWHM of(002) XRD FWHM of(102)
  [1,2)μm ≤80arcsec ≤650arcsec
  [2,3)μm ≤100arcsec ≤550arcsec
  [3,4)μm ≤120arcsec ≤450arcsec
  [4,5)μm ≤160arcsec ≤400arcsec
Edge Exclusion Zone



<2mm

Surface Roughness Ra<1.5nm(10*10μm)
Package Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.





About Us

We specialize in processing a variety of materials into wafers, substrates and customized optical glass parts.components widely used in electronics, optics, opto electronics and many other fields. We also have been working closely with many domestic and oversea universities, research institutions and companies, provide customized products and services for their R&D projects. It's our vision to maintaining a good relationship of cooperation with our all customers by our good reputations.





FAQ

Q: Are you trading company or manufacturer ?
We are factory.
Q: How long is your delivery time?
Generally it is 3-5 days if the goods are in stock.
or it is 7-10 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
Payment <=5000USD, 100% in advance.
Paymen >=5000USD, 80% T/T in advance , balance before shippment.
