2inch Aluminum Nitride Wafer Single Or Double Side Polished

Certification
China Shanghai GaNova Electronic Information Co., Ltd. certification
I'm Online Chat Now

2inch Aluminum Nitride Wafer Single Or Double Side Polished

2inch Aluminum Nitride Wafer Single Or Double Side Polished
2inch Aluminum Nitride Wafer Single Or Double Side Polished

Large Image :  2inch Aluminum Nitride Wafer Single Or Double Side Polished

Product Details:
Place of Origin: Suzhou China
Brand Name: GaNova
Certification: UKAS/ISO9001:2015
Model Number: JDWY01-001-003
Payment & Shipping Terms:
Packaging Details: Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.
Payment Terms: T/T

2inch Aluminum Nitride Wafer Single Or Double Side Polished

Description
Dimensions: φ50.8 Mm±0.1 Mm,OF(1-100),Al Face,Locating Edge 16.0± 1.0 Mm Substrate: Sapphire(Single Or Double Side Polished)
Orientation: C-plane (0001)±1˚ Conduction Type: Semi-Insulating
Edge Exclusion Zone: <2mm Product Name: Aluminum Nitride Wafer
Highlight:

2in Aluminum Nitride Wafer

,

Double Side Polished Wafer

,

Aluminum Nitride Wafer Single

2in AIN On Sapphire Wafer Sapphire Single Or Double Side Polished AlN-T-C-U-C50

2 Inch Thick Film (2,3)Um AIN On Sapphire Wafer,SSP,XRD FWHM Of(002)≤100arcsec(102) ≤550arcsec UV Disinfection LED Chip



Overview

The electricity savings of using LEDs instead of traditional cold-cathode fluorescent lamps (CCFLs) can reach 70%. Also, unlike CCFLs, AlN LEDs do not contain mercury, allowing more environmentally friendly disposal. AlN LEDs can also be used for non-line-of-sight communications.



Currently, the newest-generation AlN-on-sapphire LEDs technology is approaching 50,000 hours of life, compared with just 10,000 hours for existing AlN-on-sapphire LEDs. The cost saving will only increase with time, adds the firm.





Specification

Item AlN-T-C-U-C50
Dimensions φ50.8 mm±0.1 mm,OF(1-100),Al Face,Locating Edge 16.0± 1.0 mm
Substrate Sapphire(Single or Double Side Polished)
Thickness 1~5μm
Orientation

C-plane (0001)±1o

Conduction Type Semi-Insulating
Crystalline Quality Thickness XRD FWHM of(002) XRD FWHM of(102)
  [1,2)μm ≤80arcsec ≤650arcsec
  [2,3)μm ≤100arcsec ≤550arcsec
  [3,4)μm ≤120arcsec ≤450arcsec
  [4,5)μm ≤160arcsec ≤400arcsec
Edge Exclusion Zone



<2mm

Surface Roughness Ra<1.5nm(10*10μm)
Package Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.
