Product Details:
|
| Product Name: | 2-inch Free-standing U-GaN/SI-GaN Substrates | Dimensions: | 50.8 ± 1mm |
|---|---|---|---|
| Thickness: | 350 ± 25μm | Orientation Flat: | (1-100) ± 0.5˚, 16 ± 1mm |
| Secondary Orientation Flat: | (11-20) ± 3˚, 8 ± 1mm | Ga Face Surface Roughness: | < 0.2nm (polished) Or < 0.3nm (polished And Surface Treatment For Epitaxy) |
| Highlight: | 375um GaN Epitaxial Wafer,gallium nitride wafer UKAS,GaN Epitaxial Wafer 50.8mm |
||
350 ± 25 μm (11-20) ± 3o, 8 ± 1 mm 2-inch Free-standing U-GaN/SI-GaN Substrates
2inch C-face Un-doped n-type free-standing GaN single crystal substrate Resistivity < 0.1 Ω·cm Power device/laser wafer
Overview
The standard in semiconductor material industry specifies the method for testing the surface roughness of GaN Single Crystal Substrate with an atomic force microscope, which applies to GaN single crystal substrates grown by chemical vapor deposition and other methods with a surface roughness of less than 10nm.
| 2-inch Free-standing U-GaN/SI-GaN Substrates | |||||||
|
Excellent level (S) |
Production level(A) |
Research level (B) |
Dummy level (C) |
Note: (1) Useable area: edge and macro defects exclusion (2) 3 points: the miscut angles of positions (2, 4, 5) are 0.35 ± 0.15o |
|||
| S-1 | S-2 | A-1 | A-2 | ||||
| Dimensions | 50.8 ± 1 mm | ||||||
| Thickness | 350 ± 25 μm | ||||||
| Orientation flat | (1-100) ± 0.5o, 16 ± 1 mm | ||||||
| Secondary orientation flat | (11-20) ± 3o, 8 ± 1 mm | ||||||
| Resistivity (300K) |
< 0.5 Ω·cm for N-type (Undoped; GaN-FS-C-U-C50) or > 1 x 106 Ω·cm for Semi-insulating (Fe-doped; GaN-FS-C-SI-C50) |
||||||
| TTV | ≤ 15 μm | ||||||
| BOW | ≤ 20 μm ≤ 40 μm | ||||||
| Ga face surface roughness |
< 0.2 nm (polished) or < 0.3 nm (polished and surface treatment for epitaxy) |
||||||
| N face surface roughness |
0.5 ~1.5 μm option: 1~3 nm (fine ground); < 0.2 nm (polished) |
||||||
| Package | Packaged in a cleanroom in single wafer container | ||||||
| Useable area | > 90% | >80% | >70% | ||||
| Dislocation density | <9.9x105 cm-2 | <3x106 cm-2 | <9.9x105 cm-2 | <3x106 cm-2 | <3x106 cm-2 | ||
| Orientation:C plane (0001) off angle toward M-axis |
0.35 ± 0.15o (3 points) |
0.35 ± 0.15o (3 points) |
0.35 ± 0.15o (3 points) |
||||
| Macro defect density (hole) | 0 cm-2 | < 0.3 cm-2 | < 1 cm-2 | ||||
| Max size of macro defects | < 700 μm | < 2000 μm | < 4000 μm | ||||
