GaN Substrates Ga Face Surface Roughness < 0.2 nm (Polished) Or < 0.3 nm (Polished And Surface Treatment For Epitaxy)

Large Image : GaN Substrates Ga Face Surface Roughness < 0.2 nm (Polished) Or < 0.3 nm (Polished And Surface Treatment For Epitaxy)

Product Details:

Place of Origin:	Suzhou China
Brand Name:	GaNova
Certification:	UKAS/ISO9001:2015
Model Number:	JDCD-01-001-001

Payment & Shipping Terms:

Packaging Details:	Vacuum packing in a class 10000 clean room environment,in cassettes of 6pcs or single wafer containers.
Delivery Time:	3-4 week days
Payment Terms:	T/T
Supply Ability:	10000pcs/month

Contact Now

GaN Substrates Ga Face Surface Roughness < 0.2 nm (Polished) Or < 0.3 nm (Polished And Surface Treatment For Epitaxy)

Description

Product Name:	GaN Single Crystal Substrate	Dimensions:	10 X 10.5mm²
Thickness:	350 ±25µm	Orientation:	C Plane (0001) Off Angle Toward M-axis 0.35 ±0.15°
TTV:	≤ 10µm	Macro Defect Density:	0cm⁻²
Highlight:	Surface Treatment GaN Substrates , Epitaxy GaN Substrates , Polished GaN Substrates

10*10.5mm² C-face Un-doped n-type free-standing GaN single crystal substrate Resistivity < 0.1 Ω·cm Power device/laser

Overview
We provide high-quality GaN substrates which are produced by originally designed HVPE (Hydride Vapor Phase Epitaxy) method, utilizing more than 10 years of experience in the GaAsP epi-wafer business.

10 x 10.5 mm2 Free-standing GaN Substrates
Item	GaN-FS-C-U-S10	GaN-FS-C-N-S10	GaN-FS-C-SI-S10	Remarks: A circular arc angle (R < 2 mm) is used for distinguishing the Ga and N face.
Dimensions	10 x 10.5 mm²
Thickness	350 ±25 µm
Orientation	C plane (0001) off angle toward M-axis 0.35 ±0.15°
Conduction Type	N-type	N-type	Semi-Insulating
Resistivity(300K)	< 0.1 Ω·cm	< 0.05 Ω·cm	> 10⁶ Ω·cm
TTV	≤ 10 µm
BoW	- 10 µm ≤ BOW ≤ 10 µm
Ga Face Surface Roughness	< 0.2 nm (polished) or < 0.3 nm (polished and surface treatment for epitaxy)


N Face Surface Roughness	0.5 ~1.5 μm option: 1~3 nm (fine ground); < 0.2 nm (polished)


Dislocation Density	From 1 x 10⁵ to 3 x 10⁶cm^-2 (calculated by CL)*
Macro Defect Density	0 cm^-2
Useable Area	> 90% (edge exclusion)
Package	Packaged in a class 100 clean room environment, in 6 PCS container, under a nitrogen atmosphere

*National standards of China (GB/T32282-2015)
