Product Details:
|
| Product Name: | 4inch GaN-on-Sapphire Blue/Green LED Wafer | Type: | Flat Sapphire |
|---|---|---|---|
| Thickness: | 650 ± 25μm | Orientation: | C Plane (0001) Off Angle Toward M-axis 0.2 ± 0.1° |
| Polish: | Single Side Polished (SSP) / Double Side Polished (DSP) | Dimension: | 100 ± 0.2mm |
| Highlight: | 625um gan epi wafer,675um gan epi wafer,4 inch gan epitaxial wafer |
||
Substrate Thickness 650 ± 25 μm 4 Inch Blue LED GaN Epitaxial Wafer On Sapphire SSP Flat Sapphire
4 inch Blue LED gallium nitride GaN epitaxial wafer on sapphire SSP
For example, gallium nitride (GaN) is the substrate which makes violet (405 nm) laser diodes possible, without use of nonlinear optical frequency-doubling. Its sensitivity to ionizing radiation is low (like other group III nitrides), making it a suitable material for solar cell arrays for satellites. Military and space applications could also benefit as devices have shown stability in radiation environments.
| 4inch GaN-on-Sapphire Blue/Green LED Wafer | ||||
|
Substrate |
Type | Flat Sapphire |
|
|
| Polish | Single side polished (SSP) / Double side polished (DSP) | |||
| Dimension | 100 ± 0.2 mm | |||
| Orientation | C plane (0001) off angle toward M-axis 0.2 ± 0.1° | |||
| Thickness | 650 ± 25 μm | |||
|
Epilayer |
Structure | 0.2μm pGaN/0.5μm MQWs/2.5μm nGaN/2.0μm uGaN | ||
| Thickness | 5.5 ± 0.5μm | |||
| Roughness (Ra) | <0.5 nm | |||
| Dislocation density | < 5 × 108 cm-2 | |||
| Wavelength | Blue LED | Green LED | ||
| 465 ± 10 nm | 525 ± 10 nm | |||
| Wavelength FWHMs | < 25 nm | < 40 nm | ||
| Chip Performance | Cut-in voltage@1μA | 2.3-2.5V | 2.2-2.4V | |
| Useable Area | > 90% (edge and macro defects exclusion) | |||
|
Package |
Packaged in a cleanroom in a single wafer container |
|||
