S-C-N Conduct 2inch GaAs Undoped Substrates High Electron Mobility

Description
Product Name: GaAs-Si Wafer Conduct Type: S-C-N
Dopant: GaAs-Si Orientation Angle:
OF Orientation: EJ[0-1-1]±0.5° OF Length (mm): 17±1
Highlight:

S-C-N semiconductor substrate

,

GaAs-Si Wafer ISO

,

semiconductor substrate 17mm

S-C-N Conduct 2inch GaAs (100) Undoped Substrates High Electron Mobility



Overview

With the development of mini-LED and micro-LED, red light LEDs produced with GaAs substrates are increasingly used for display screens and in AR/VR.
GaAs is a semi-conductor material with excellent performance characteristics including direct band gap, high electron mobility, high-frequency low noise, and high conversion efficiency.



GaAs-Si Wafer

Growth Method

VGF
Conduct Type S-C-N
Dopant GaAs-Si
Orientation (100)15°±0.5° Off Toward<111>A
Orientation Angle
OF Orientation EJ[0-1-1]±0.5°
OF Length (mm) 17±1
IF Orientation EJ[0-11]±0.5°
IF Length(mm) 7±1
Diameter(mm) 50.8±0.2
CC(/c.c.) 0.4E18~1E18
Resistivity(ohm.cm) N/A
Mobility(cm2/v.s) ≥1000
EPD(/cm2) ≤5000
Thickness(um) 350±20
TTV(um) <10
TTR(um) <10
Bow(um) <15
Warp(um) <15
Surface Side1:Polished Side2:Etched
Packaging Cassette or single
