Description
Product Name: GaAs-Si Wafer Growth Method: VGF
Conduct Type: S-C-N Dopant: GaAs-Si
Orientation Angle: OF Orientation: EJ[0-1-1]±0.5°
Highlight:

17mm GaAs Epi Wafer

,

epitaxial wafer 50.8mm

,

GaAs Epi Wafer 50.8mm

17±1mm OF Length 2inch GaAs (100) Undoped Substrates 50.8±0.2mm



Overview

The conversion efficiency of a high-efficiency solar-cell panel based on GaAs is up to 40%. At present, such solar-cell panels are widely used in unmanned aerial vehicle and solar auto applications.

GaAs applications cover a large variety of transistors for industry spanning optical fiber communication, wireless networks (WLAN), mobile handsets, blue tooth communications, satellite communications, monolithic microwave integrated circuits (MMIC) for 5G, as well as radio frequency integrated circuits (RFIC).



GaAs-Si Wafer

Growth Method

VGF
Conduct Type S-C-N
Dopant GaAs-Si
Orientation (100)15°±0.5° Off Toward<111>A
Orientation Angle
OF Orientation EJ[0-1-1]±0.5°
OF Length (mm) 17±1
IF Orientation EJ[0-11]±0.5°
IF Length(mm) 7±1
Diameter(mm) 50.8±0.2
CC(/c.c.) 0.4E18~1E18
Resistivity(ohm.cm) N/A
Mobility(cm2/v.s) ≥1000
EPD(/cm2) ≤5000
Thickness(um) 350±20
TTV(um) <10
TTR(um) <10
Bow(um) <15
Warp(um) <15
Surface Side1:Polished Side2:Etched
Packaging Cassette or single
