JDCD06-001-003 4-Inch Silicon Wafer MEMS Devices, Integrated Circuits,Dedicated Substrates For Discrete Devices

Certification
China Shanghai GaNova Electronic Information Co., Ltd. certification
I'm Online Chat Now

JDCD06-001-003 4-Inch Silicon Wafer MEMS Devices, Integrated Circuits,Dedicated Substrates For Discrete Devices

JDCD06-001-003 4-Inch Silicon Wafer MEMS Devices, Integrated Circuits,Dedicated Substrates For Discrete Devices
JDCD06-001-003 4-Inch Silicon Wafer MEMS Devices, Integrated Circuits,Dedicated Substrates For Discrete Devices

Large Image :  JDCD06-001-003 4-Inch Silicon Wafer MEMS Devices, Integrated Circuits,Dedicated Substrates For Discrete Devices

Product Details:
Place of Origin: Suzhou China
Brand Name: GaNova
Certification: UKAS/ISO9001:2015
Model Number: JDCD06-001-003
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Vacuum packing in a class 10000 clean room environment,in cassettes of 25pcs or single wafer containers.
Delivery Time: 3-4 week days
Payment Terms: T/T
Supply Ability: 50000pcs/month

JDCD06-001-003 4-Inch Silicon Wafer MEMS Devices, Integrated Circuits,Dedicated Substrates For Discrete Devices

Description
Diameter: 4" Grade: Prime
Growth Method: CZ Orientation: <1-0-0>,<1-1-1>,<1-1-0>
Type/Dopant: P Type/Boron,N Type/Phos,N Type/As, N Type/Sb Thickness(μm): 525
Thickness Tolerance: Standard ± 25μm,Maximum Capabilities ± 5μm Resistivity: 0.001-100 Ohm-cm
Surface Finished: P/E,P/P,E/E,G/G TTV(μm): Standard <10 Um,Maximum Capabilities<5 Um
Bow/Warp: Standard <40 Um,Maximum Capabilities<20 Um Particle: <10@0.5um; <10@0.3um; <10@0.2um;
Highlight:

MEMS Devices Silicon Wafer

4-inch silicon wafer MEMS devices, integrated circuits,dedicated substrates for discrete devices




A silicon wafer is a material essential for manufacturing semiconductors, which are found in all kinds of electronic devices that enrich our lives. Few of us have a chance to encounter an actual silicon wafer in daily life.
A silicon wafer is a thin slice of crystal semiconductor, such as a material made up from silicon crystal, which is circular in shape.
Silicon wafers absorb the photons in sunlight and this in turn create electricity. Many companies use silicon wafers in their product testing. In this purpose, a lot of time the product or prototype is created and tested.



Specification

silicon wafer

Diameter



2"/3"/4"/5"/6"/8"/12"
Grade Prime
Growth Method CZ
Orientation <1-0-0>,<1-1-1>,<1-1-0>
Type/Dopant P Type/Boron,N Type/Phos,N Type/As, N Type/Sb
Thickness(μm)

279/380/525/625/675/725/775

Thickness Tolerance Standard ± 25μm,Maximum Capabilit/ies ± 5μm
Resistivity 0.001-100 ohm-cm
Surface Finished P/E,P/P,E/E,G/G
TTV(μm) Standard <10 um,Maximum Capabilities<5 um
Bow/Warp Standard <40 um,Maximum Capabilities<20 um
Particle <10@0.5um; <10@0.3um; <10@0.2um;
