Sn Doping Ga2O3 Wafer Single Crystal Substrate 10x10mm2

Description
Thickness: 0.6~0.8mm Product Name: Single Crystal Substrate
Orientation: (201) Polished Surface: Single Side Polished
FWHM: <350arcsec Ra: ≤0.3nm
Highlight:

Sn Doping Ga2O3 Wafer

,

0.8mm Gallium Oxide wafer

,

Ga2O3 Wafer 10x10mm2

10x10mm2 (-201) Fe-doped free-standing Ga2O3 single crystal substrate Product grade single polishing Thickness 0.6~0.8mm FWHM<350arcsec,Ra≤0.3 nm Optoelectronic devices, insulating layers of semiconductor materials, and UV filters



Among these different phases of Ga2O3, the orthorhombic β-gallia structure (β-phase or β-Ga2O3) is the most stable crystal structure and has attracted most of the recent attention. The different polymorphs can be either insulators or conductors, depending on the growth conditions.





Gallium nitride substrate--Product level
Dimensions 10*15mm 10*10mm
Thickness 0.6~0.8mm
Orientation (201)
Doping Fe Sn
Polished surface Single side polished
Resistivity/Nd-Na / <9E18
FWHM <350arcsec
Ra ≤0.3nm
Package Packaged in a class 100 clean room environment, under a nitrogen atmosphere
