Single Side Polished Ga2O3 Wafer Single Crystal Substrate

Certification
China Shanghai GaNova Electronic Information Co., Ltd. certification
I'm Online Chat Now

Single Side Polished Ga2O3 Wafer Single Crystal Substrate

Single Side Polished Ga2O3 Wafer Single Crystal Substrate
Single Side Polished Ga2O3 Wafer Single Crystal Substrate
Single Side Polished Ga2O3 Wafer Single Crystal Substrate Single Side Polished Ga2O3 Wafer Single Crystal Substrate

Large Image :  Single Side Polished Ga2O3 Wafer Single Crystal Substrate

Product Details:
Place of Origin: Suzhou China
Brand Name: GaNova
Certification: UKAS/ISO9001:2015
Model Number: JDCD04-001-002
Payment & Shipping Terms:
Packaging Details: Vacuum packing in a class 10000 clean room environment,in cassettes of 6pcs or single wafer containers.
Delivery Time: 3-4 week days

Single Side Polished Ga2O3 Wafer Single Crystal Substrate

Description
Product Name: Single Crystal Substrate Thickness: 0.6~0.8mm
Polished Surface: Single Side Polished Orientation: (201)
FWHM: <350arcsec Ra: ≤0.3nm
Highlight:

Side Polished Ga2O3 Wafer

,

0.6mm gallium nitride substrate

,

Ga2O3 Wafer UKAS

10x10mm2 (-201) Fe-doped free-standing Ga2O3 single crystal substrate Product grade single polishing Thickness 0.6~0.8mm FWHM<350arcsec,Ra≤0.3 nm Optoelectronic devices, insulating layers of semiconductor materials, and UV filters





Gallium Oxide (Ga2O3) is emerging as a viable candidate for certain classes of power electronics, solar blind UV photodetectors, solar cells and sensors with capabilities beyond existing technologies due to its large bandgap. It is usually reported that there are five different polymorphs of Ga2O3, namely the monoclinic (β−Ga2O3), rhombohedral (α), defective spinel (γ), cubic (δ), or orthorhombic (ε) structures.





Gallium nitride substrate--Product level
Dimensions 10*15mm 10*10mm
Thickness 0.6~0.8mm
Orientation (201)
Doping Fe Sn
Polished surface Single side polished
Resistivity/Nd-Na / <9E18
FWHM <350arcsec
Ra ≤0.3nm
Package Packaged in a class 100 clean room environment, under a nitrogen atmosphere
